• 原装进口气动球阀 气动球阀价格 进口不锈钢气动球阀

    详细信息

     品牌:TRAIC  型号:VTAIC  结构形式:螺纹
     材质:不锈钢  连接形式:内螺纹  公称通径:50 mm
     适用介质:水  压力环境:常压  工作温度:常温
     驱动方式:气动  流动方向:双向  标准:国标
     零部件及配件:执行器  用途:疏水  类型:二通式
     作用对象:水
    Series FD9-F1 Firesafe 150# Flanged Direct Mount Automated Ball Valve Packages
    Triac FD9-F1 Series Direct Mount 150# Flanged Firesafe Ball Valves feature a direct mount automation pad. The high quality investment castings feature a fully machined bore. The superior live-loaded packing system is accomplished with Belleville washers, "V" ring packing and unique primary pyramidal stem seal. This advanced sealing system provides for protection against stem leaks experienced by ordinary ball valves.
    Reinforced RTFE seats are standard, but various options are available for seat materials. The 50/50 seat option is excellent for services that call for higher temperatures and more difficult applications, including steam. Call us for details.
    The Triac Controls Series FD9-F1 Firesafe 150# flanged direct mount automated ball valve package features:
    • Firesafe
    • Full Port Valve
    • Class 150
    • 1/2" – 6"
    • 316SS or CS Body
    • 316SS Ball & Stem
    • Belleville Washers
    • Chevron Packing
    • RTFE Seats Standard
    • Pyramidal Stem Design

    气动丝口球阀资料
    Series 22 - 2 Piece Direct Mount Automated Ball Valve Packages
    Available in Pneumatic Spring Return, Pneumatic Double Acting and Electric automated ball valve packages.
    The Triac Controls 2 Piece Direct Mount automated ball valve packages feature:
    • Full Port Valve
    • 1000 WOG
    • 2-Piece High Cycle Design
    • 1/4" – 3"
    • Direct Actuator Mount
    • 316 SS Body, Ball and Stem
